Elite ZR1 1-Piece Low Temperature Carbon Steel Ball Valve

Class 150 | Flanged | 2″ to 8″ | Regular Port | ASTM A352

Product Description

Delivering a low temperature carbon steel ball valve, that is both long-lasting and cost effective, Elite Valve manufactures solutions that are best suited for industrial and commercial use. Perfect for liquid, gas, steam and water applications, Elite Valve’s 1-piece low temperature carbon steel ball valve will with stand the harshest of operating conditions and service environments.

Features Include

  • Regular Port
  • Lever operated
  • Cavity relieving seats, anti-static device
  • Blow-out proof stem
  • ISO mounting pad
  • Reduced bore, 1 piece uni-body floating ball
  • Available in sizes of 2” x 1½” to 8” x 6”
  • Class 150 pressure rated

Specifications

  • Pressure Test per API 598
  • Design Standard per API 608
  • NACE MR0175
  • Markings per MSS-SP25
  • Face to Face to ASME/ANSI B16.10 Short Pattern
  • Designed to ASME/ANSI Class 150-B16.34
  • Fire-safe to API-607, latest Ed.

End Connection

  • Flanged (FLG)
